| Body type | Hatchback |
|---|---|
| Power | 76 Hp |
| Engine Displacement | 1300 cm3 or 1.3L or 79.3 cu-in |
| Transmission Gearbox | Manual |
| Fuel Type | Gasoline |
| Drive wheel | FF |
| Vin | TSMMMA53S00****18 |
| Price (out of date) | $2309 |
Frequently Asked Questions | |
|---|---|
| What is the body type, 2006 Suzuki Wagon R Plus II? | Hatchback, 5 Seats, 5 Doors |
| How much power, 2006 Suzuki Wagon R Plus 1.3 MT GL? | 76 Hp |
| What is the engine size, Suzuki Wagon R Plus II 2006 Hatchback 1.3 MT GL (76 Hp)? | 1.3L or 1298cm3 |
| How many gears, What type is the gearbox, 2006 Suzuki Wagon R Plus Hatchback 1.3 MT GL (76 Hp)? | 5 speed Manual |
| What is the drivetrain, 2006 Suzuki Wagon R Plus II? | Front |
| How long is this vehicle, 2006 Suzuki Wagon R Plus 1.3 MT GL? | 3500 mm |
| How wide is the vehicle, Suzuki Wagon R Plus II 2006 Hatchback 1.3 MT GL (76 Hp)? | 1600 mm |
| What is the gross weigh, 2006 Suzuki Wagon R Plus Hatchback 1.3 MT GL (76 Hp)? | 1460 kg |
Suzuki Wagon R Plus II 1.3 MT GL (76 Hp) 2003, 2004, 2005, 2006 Specs
General information | |
|---|---|
| Complectation name | 1.3 MT GL |
| Production start year | 2003 |
| Production end year | 2006 |
| Drive type | Front |
| Frame type | Hatchback |
| Transmission type | 5 speed Manual |
| Engine volume, cc | 1298 |
| Clearance, mm | 165 |
| Manufacturing country | Japan |
| Doors | 5 |
Vehicle generation | |
| Generation name | MM |
| Generation number | 2 |
| Facelift number | 1 |
| Production start year | 2003 |
| Production end year | 2006 |
Engine, transmission and steering specs | |
Engine specs | |
| Engine name | G13BB |
| Fuel | Petrol (Gasoline) |
| Engine type | In-line, 4-cylinder |
| Has turbo | no |
| Max power, hp | 76 |
| Max power RPM, rpm | 5500 |
| Max power, hp (kWt) / rpm | 76 (56) / 5500 |
| Max torque, N*m | 115 |
| Max torque RPM, rpm | 4250 |
| Max torque, N*m (kg*m) / rpm | 115 (12) / 4250 |
| Valves per cylinder | 4 |
| Compression ratio | 9.5 |
| Bore, mm | 74 |
| Stroke, mm | 75.5 |
| Engine additional info | SOHC |
Transmission | |
| 1st gear ratio | 3.41 |
| 2nd gear ratio | 1.9 |
| 3rd gear ratio | 1.28 |
| 4th fear ratio | 0.96 |
| 5th gear ratio | 0.76 |
| Rear gear ratio | 3.27 |
| Main gear ratio | 4.1 |
Steering | |
| Power steering | no |
| Electric power steering | yes |
| Steereing gear type | Gear rail |
Dimensions | |
Frame dimensions | |
| Exterior length, mm | 3500 |
| Exterior width, mm | 1600 |
| Exterior height, mm | 1705 |
Interior dimensions | |
| Capacity | 5 |
| Seat rows | 2 |
Chassis dimensions | |
| Wheel base, mm | 2350 |
| Turning radius, m | 4.9 |
| Wheel spacing front | 1420 |
| Wheel spacing rear | 1385 |
Weight and permissible load | |
| Mass, kg | 1040 |
| Max capacity | 420 |
| Max. weight | 1460 |
Volumes | |
| Fuel tank capacity, l | 41 |
Other | |
| Addinfo | Door moldings; "Child" lock |
Suspension specs | |
Suspension specs | |
| Front suspension | Independent, Spring McPherson |
| Rear suspension | Dependent, multilever |
Wheel rims | |
| Aluminium wheel | yes |
| Front wheel disk | 14X5.5J |
| Rear wheel disk | 14X5.5J |
Tires | |
| Front wheels | 165/60 R14 |
| Rear wheels | 165/60 R14 |
Brakes | |
| Front brake | Ventilated discs |
| Rear brake | drum brakes |
Exterior | |
Headlights | |
| Halogen headlights | yes |
| Front fog lamps | yes |
| Rear fog lamps | yes |
| Additional stop light | yes |
Side mirrors | |
| Power adjustable door mirrors | yes |
Windows | |
| Privacy glass | yes |
| Rear glass heat | yes |
Accessories | |
| Roof rail | yes |
| Rear spoiler | yes |
| Bumpers | painted in body color; grille with chrome edging |
| Back wiper | yes |
Interior | |
Steering wheel and center panel | |
| Leather winding | no |
| Tachometer | yes |
Interior design | |
| Cloth upholstery | yes |
| Leather upholstery | no |
Seats | |
| Front seats ajust | In 6 directions. |
| 2nd row | 50/50 ratio fold seat |
| Seat lifter | yes |
| Headrests for seats | 4 |
| Seats pockets | yes |
Electric interior package | |
| Centralized door lock | yes |
| Power window front | yes |
| Power window rear | no |
Additional interior equipment | |
| Smokers packet | yes |
| AC plug | yes |
Safety | |
Airbags | |
| Drivers airbag | yes |
| Passengers airbag | yes |
Active and passive safety | |
| Safety belt pretensioner | yes |
Electronic security and traffic control systems | |
| ABS | yes |
Amenity | |
Microclimate | |
| Air conditioner | yes |
Audio systems | |
| Radio | option |
| CD player | option |
| Additional sound equipment | Audio Prep |
Additional amenities | |
| Antidazzle rearview mirror | no |
| Mirrors in sunshields | yes |
| Lagage box | yes |
| Blind in luggage compartment | yes |
Car safety | |
| Immobilizer | yes |
2006 Suzuki Wagon R Plus II 1.3 MT GL (76 Hp) specs
|
1998 saw the introduction of the second-generation Wagon R in Japan, with the Wagon R+ replacing the Wagon R Wide in 1999 - this was brought to Europe in 2000. This is also produced in Esztergom in Hungary and Gurgaon, India. The Opel Agila is a badge engineered version of the Suzuki Wagon R+, also introduced in summer 2000. A third generation Wagon R was launched in Japan in September 2003 for their 10th Anniversary, but only as a K-car - no oversized version (like the previous Wide and +) was developed in either Japan or Europe. The third generation was facelifted in September 2005. The fourth generation Wagon R was launch in Japan in September 2008 along with 3 variants, Stingray Wagon R, AZ Wagon and AZ Wagon Custom. The main difference between this new generation is bigger door and the absence of the C-pillar of the car. Powertrain options include naturally aspirated and turbocharged 660cc engines with the latter developing an output of 64 HP, mated to a 4-speed automatic, a 5-speed manual or a CVT transmission. As with many other Japanese market models, customers can choose between front-wheel and all-wheel-drive versions. » Read More About Suzuki Wagon R Plus |
