Body type | SUV |
---|---|
Power | 105 Hp |
Engine Displacement | 2500 cm3 or 2.5L or 152.5 cu-in |
Color | green |
Transmission Gearbox | Manual |
Fuel Type | Diesel |
Drive wheel | 4WD |
Vin | KMXKPE1BPVU****14 |
Price (out of date) | $4408 |
Frequently Asked Questions | |
---|---|
What is the body type, 1997 Hyundai Galloper II? | SUV, 6 Seats, 5 Doors |
How much power, 1997 Hyundai Galloper 2.5 TCI MT EXD? | 105 Hp |
What is the engine size, Hyundai Galloper II 1997 SUV 2.5 TCI MT EXD (105 Hp)? | 2.5L or 2476cm3 |
How many gears, What type is the gearbox, 1997 Hyundai Galloper SUV 2.5 TCI MT EXD (105 Hp)? | 5 speed Manual |
What is the drivetrain, 1997 Hyundai Galloper II? | All wheel drive (4x4) |
How long is this vehicle, 1997 Hyundai Galloper 2.5 TCI MT EXD? | 4714 mm |
How wide is the vehicle, Hyundai Galloper II 1997 SUV 2.5 TCI MT EXD (105 Hp)? | 1770 mm |
What is the gross weigh, 1997 Hyundai Galloper SUV 2.5 TCI MT EXD (105 Hp)? | 2305 kg |
How much trunk (boot) space, 1997 Hyundai Galloper II? | 663 l |
Hyundai Galloper II 2.5 TCI MT EXD (105 Hp) 1997, 1998, 1999, 2000, 2001, 2002, 2003 Specs
General information | |
---|---|
Complectation name | 2.5 TCI MT EXD |
Production start year | 1997 |
Production end year | 2003 |
Drive type | All wheel drive (4x4) |
Frame type | SUV |
Transmission type | 5 speed Manual |
Engine volume, cc | 2476 |
Clearance, mm | 210 |
Manufacturing country | South Korea |
Doors | 5 |
Engine, transmission and steering specs | |
Engine specs | |
Engine name | D4BH |
Fuel | Diesel |
Engine type | In-line, 4-cylinder |
Has turbo | yes |
Turbo type | Turbine |
Max power, hp | 105 |
Max power RPM, rpm | 4000 |
Max power, hp (kWt) / rpm | 105 (77) / 4000 |
Max torque, N*m | 240 |
Max torque RPM, rpm | 2000 |
Max torque, N*m (kg*m) / rpm | 240 (24) / 2000 |
Compression ratio | 21 |
Bore, mm | 91.1 |
Stroke, mm | 95 |
Steering | |
Power steering | no |
Steereing gear type | Ball nut screw |
Dimensions | |
Frame dimensions | |
Exterior length, mm | 4714 |
Exterior width, mm | 1770 |
Exterior height, mm | 1900 |
Interior dimensions | |
Capacity | 6 |
Seat rows | 3 |
Chassis dimensions | |
Wheel base, mm | 2695 |
Wheel spacing front | 1435 |
Wheel spacing rear | 1450 |
Front overhang | 770 |
Rear overhang | 1154 |
Weight and permissible load | |
Mass, kg | 1915 |
Max. weight | 2305 |
Volumes | |
Fuel tank capacity, l | 92 |
Trunk volume | 663 |
Suspension specs | |
Suspension specs | |
Front suspension | Independent on double wishbones |
Rear suspension | Dependent, spring loaded |
Tires | |
Front wheels | 265/70 R15 |
Rear wheels | 265/70 R15 |
Brakes | |
Front brake | Discs |
Rear brake | drum brakes |
1997 Hyundai Galloper II 2.5 TCI MT EXD (105 Hp) specs
|
It was available with a 3-door body on a short wheel base (Innovation) or 5-door body on long wheel base (Exceed / Galloper II). » Read More About Hyundai Galloper |
