Toyota Corolla XI (E170) 1.4 D-4D (90 Hp) has been in production since 2012 - 2015. Cars comes in Sedan body types and can be suited with Diesel engine types with a volume of 1.4L liters, engines produces a power of 90 Hp. Fuel consumption of Toyota Corolla XI (E170) 1.4 D-4D (90 Hp) is 4.1 l/100 km. The overall dimensions of the car are 4620x1775x1465 mm, and the weight is from 1300 kg.
General data
Generation
Corolla XI (E170)
Modification
1.4 D-4D (90 Hp)
Start of production
2012 year
End of production
2015 year
Powertrain Architecture
Internal Combustion engine
Body type
Sedan
Seats
5
Doors
4
Fuel Type
Diesel
Model
1ND-TV
Fuel consumption (economy), emissions
Fuel consumption - urban
4.9 l/100 km
Fuel consumption - extra urban
3.6 l/100 km
Fuel consumption - combined
4.1 l/100 km
CO2 emissions
100 g/km
Emission standard
Euro 5 J
Performance specs
Acceleration 0 - 100 km/h (0 - 62 mph)
12.5 sec
Maximum speed
180 km/h
Weight-to-power ratio
14.4 kg/Hp, 69.2 Hp/tonne
Engine technical data
Power
90 Hp @ 3800 rpm.
Power per litre
66 Hp/l
Torque
205 Nm @ 1800-2800 rpm.
Engine location
Front, Transverse
Engine displacement
1364 cm3
Number of cylinders
4
Position of cylinders
Inline
Cylinder Bore
73 mm
Piston Stroke
81.5 mm
Compression ratio
16.5
Number of valves per cylinder
2
Fuel System
Diesel Commonrail
Engine aspiration
Turbocharger, Intercooler
Valvetrain
SOHC
Engine oil capacity
3.7-3.9 l
Coolant
5.6 l
Engine systems
Particulate filter
Suspension and brakes specs
Drivetrain Architecture
The Internal combustion engine (ICE) drives the front wheels of the vehicle.
