General data |
|---|
| Generation | B-class (W245 facelift 2008) |
|---|
| Modification | B 180 CDI (109 Hp) Autotronic |
|---|
| Start of production | April, 2008 year |
|---|
| End of production | April, 2010 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | MPV |
|---|
| Seats | 5 |
|---|
| Doors | 5 |
|---|
| Fuel Type | Diesel |
|---|
| Model | OM 640.940 |
|---|
Fuel consumption (economy), emissions |
|---|
| Fuel consumption - urban | 6.9-7.3 l/100 km |
|---|
| Fuel consumption - extra urban | 4.9-5.3 l/100 km |
|---|
| Fuel consumption - combined | 5.6-6 l/100 km |
|---|
| CO2 emissions | 148-158 g/km |
|---|
| Emission standard | Euro 4 |
|---|
Performance specs |
|---|
| Acceleration 0 - 100 km/h (0 - 62 mph) | 11.8 sec |
|---|
| Maximum speed | 178 km/h |
|---|
| Weight-to-power ratio | 12.8 kg/Hp, 78.1 Hp/tonne |
|---|
Engine technical data |
|---|
| Power | 109 Hp @ 4200 rpm. |
|---|
| Power per litre | 54.7 Hp/l |
|---|
| Torque | 250 Nm @ 1600-2600 rpm. |
|---|
| Engine location | Front, Transverse |
|---|
| Engine displacement | 1991 cm3 |
|---|
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore | 83 mm |
|---|
| Piston Stroke | 92 mm |
|---|
| Compression ratio | 18 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Diesel Commonrail |
|---|
| Engine aspiration | Turbocharger, Intercooler |
|---|
| Valvetrain | DOHC |
|---|
| Engine oil capacity | 5.4-5.8 l |
|---|
| Engine systems | Particulate filter |
|---|
| Power | Electric Steering |
|---|
Suspension and brakes specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (automatic transmission) | Autotronic |
|---|
| Front suspension | Independent type McPherson, Transverse stabilizer |
|---|
| Rear suspension | Helical spring, Transverse stabilizer |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Tires size | 205/55 R16 |
|---|
| Wheel rims size | 6J x 16 |
|---|
Dimensions |
|---|
| Length | 4273 mm |
|---|
| Width | 1777 mm |
|---|
| Width | 2035 mm |
|---|
| Height | 1604 mm |
|---|
| Wheelbase | 2778 mm |
|---|
| Front track | 1552 mm |
|---|
| Rear (Back) track | 1547 mm |
|---|
| Drag coefficient (Cd) | 0.30 |
|---|
| Minimum turning circle (turning diameter) | 11.95 m |
|---|
Weights, volume and space |
|---|
| Kerb Weight | 1395 kg |
|---|
| Max. weight | 1880 kg |
|---|
| Max load | 485 kg |
|---|
| Trunk (boot) space - minimum | 544 l |
|---|
| Trunk (boot) space - maximum | 2245 l |
|---|
| Fuel tank capacity | 54 l |
|---|
| Max. roof load | 75 kg |
|---|
| Permitted trailer load with brakes (12%) | 1500 kg |
|---|
| Permitted trailer load without brakes | 715 kg |
|---|
| Permitted towbar download | 75 kg |
|---|
Mercedes-Benz B-class (W245 facelift 2008) B 180 CDI (109 Hp) Autotronic has been in production since 2008 - 2010. Cars comes in MPV body types and can be suited with Diesel engine types with a volume of 2L liters, engines produces a power of 109 Hp. The overall dimensions of the car are 4273x1777x1604 mm, and the weight is from 1395 kg.
