1991 Toyota Granvia 3.0DT G
More photos of Toyota Granvia
Toyota Granvia Problems
Failing to start
1997, Failed to start in the morning. What can
be the problem. The car was parked at night. In...
Wheel Alignment specs.
2002, Need new tyres and an alignment but was
told they can't unless I provide them with
...
Front sway bar link bushes
1997, Front sway bar link bushes - finding that
the steering area of my van including suspensi...
Toyota Granvia Problems
Failing to start
1997, Failed to start in the morning. What can
be the problem. The car was parked at night. In...
Wheel Alignment specs.
2002, Need new tyres and an alignment but was
told they can't unless I provide them with
...
Front sway bar link bushes
1997, Front sway bar link bushes - finding that
the steering area of my van including suspensi...
| Body type | Minivan |
|---|---|
| Power | 130 Hp |
| Engine Displacement | 3000 cm3 or 3L or 183 cu-in |
| Color | gray |
| Transmission Gearbox | Automatic |
| Fuel Type | Diesel |
| Drive wheel | 4WD |
| Mileage | 186411 Miles |
| Vin | KCH160****61 |
| Price (out of date) | $5105 |
Frequently Asked Questions | |
|---|---|
| What is the body type, Toyota Granvia Minivan 1991? | Minivan, 8 Seats, 4 Doors |
| How much power, Toyota Granvia KD-KCH16W 1991? | 130 Hp |
| What is the engine size, 1991 Toyota Granvia 3.0DT G? | 3L or 2982cm3 |
| How many gears, What type is the gearbox, Toyota Granvia 1991 Minivan 3.0DT G (130 Hp)? | Automatic transmission 4 |
| What is the drivetrain, 1991 Toyota Granvia Minivan 3.0DT G (130 Hp)? | All wheel drive (4x4) |
| How long is this vehicle, Toyota Granvia Minivan 1991? | 4715 mm |
| How wide is the vehicle, Toyota Granvia KD-KCH16W 1991? | 1800 mm |
Toyota Granvia KD-KCH16W 3.0DT G (130 Hp) 1995, 1996 Specs
General information | |
|---|---|
| Complectation name | 3.0DT G |
| Production start year | 1995 |
| Production end year | 1996 |
| Price of new car in Tokyo, yen | 3114000 |
| Drive type | All wheel drive (4x4) |
| Frame type | Minivan |
| Transmission type | Automatic transmission 4 |
| Engine volume, cc | 2982 |
| Frame name | KD-KCH16W |
| Clearance, mm | 175 |
| Doors | 4 |
| Right hand drive | yes |
| Left hand drive | no |
Vehicle generation | |
| Generation name | xH10 |
| Generation number | 1 |
| Production start year | 1995 |
| Production end year | 1997 |
Engine, transmission and steering specs | |
Engine specs | |
| Engine name | 1KZ-TE |
| Fuel | Diesel |
| Engine type | water cooling 4 cylinder SOHC |
| Has turbo | yes |
| Turbo type | Turbine |
| Max power, hp | 130 |
| Max power RPM, rpm | 3600 |
| Max power, hp (kWt) / rpm | 130 (96) / 3600 |
| Max torque, N*m | 289 |
| Max torque RPM, rpm | 2000 |
| Max torque, N*m (kg*m) / rpm | 289 (29) / 2000 |
| Compression ratio | 21 |
| Bore, mm | 96 |
| Stroke, mm | 103 |
Fuel consumption | |
| Fuel consumption (60 km/h mode), l/100km | 6.8 |
Transmission | |
| 1st gear ratio | 2.804 |
| 2nd gear ratio | 1.531 |
| 3rd gear ratio | 1 |
| 4th fear ratio | 0.705 |
| Rear gear ratio | 2.393 |
Steering | |
| Power steering | yes |
Dimensions | |
Frame dimensions | |
| Exterior length, mm | 4715 |
| Exterior width, mm | 1800 |
| Exterior height, mm | 1995 |
Interior dimensions | |
| Capacity | 8 |
| Interior length, mm | 2910 |
| Interior width, mm | 1635 |
| Interior height, mm | 1375 |
Chassis dimensions | |
| Wheel base, mm | 2985 |
| Front axle length, mm | 1550 |
| Rear axle length, mm | 1540 |
| Turning radius, m | 6.3 |
| Wheel spacing front | 1550 |
| Wheel spacing rear | 1540 |
Weight and permissible load | |
| Mass, kg | 2050 |
Volumes | |
| Fuel tank capacity, l | 75 |
Suspension specs | |
Suspension specs | |
| Front stabilizer | yes |
| Front suspension | Independent on double wishbones |
| Rear stablilizer | no |
| Rear suspension | Independent, on the wishbone |
| LSD | option |
Tires | |
| Front wheels | 215/70R15 98S |
| Rear wheels | 215/70R15 98S |
Brakes | |
| Front brake | Ventilated discs |
| Rear brake | drum brakes |
| Brake front search | 1 |
| Rear brake | 2 |
Exterior | |
Headlights | |
| Xenon lamps | no |
| Front fog lamps | yes |
| Rear fog lamps | no |
| Additional stop light | yes |
| Cornering lamps | no |
Side mirrors | |
| Power adjustable door mirrors | yes |
Windows | |
| Ultraviolet glass protection | yes |
Roof | |
| Sunroof | no |
| Tilt sunroof | option |
| Twin sunroof | option |
Accessories | |
| Roof rail | no |
| Front spoiler | no |
| Rear spoiler | option |
| Back wiper | yes |
Body color | |
| Colors | 20 2201 2202 |
Interior | |
Steering wheel and center panel | |
| Leather winding | no |
| Telescopic steering | no |
| Tilt steering | yes |
| Tachometer | yes |
Interior design | |
| Leather seat | no |
| Wood panel | no |
Seats | |
| Reclining seats | yes |
| Removable seats | no |
| Turning seats | yes |
Electric interior package | |
| Power adjustable driver seat | yes |
| Power ajustable front seat | yes |
| Power ajustable back seat | no |
| Centralized door lock | yes |
| Keyless enter | option |
| Power window | yes |
| Central power window control | no |
Safety | |
Airbags | |
| Drivers airbag | yes |
| Passengers airbag | no |
| Side airbag | no |
Children safety | |
| Child car restraints | yes |
Active and passive safety | |
| Durable frame | no |
| Side impact bar | yes |
| 3 point safety belt | yes |
| Safety belt pretensioner | no |
| Safety belt limiter | no |
Electronic security and traffic control systems | |
| Break assist | no |
| traction control | no |
| Cruise control | no |
Amenity | |
Microclimate | |
| Cooler | no |
| Automatic air conditioning | no |
| Twin conditioning system | yes |
| Air purifier | no |
Audio systems | |
| Radio | yes |
| Autoreverse casette | yes |
| CD player | option |
| CD changer | no |
| MD palyer | no |
| MD changer | no |
Navigation and video equipment | |
| Parking assist system | no |
1991 Toyota Granvia KD-KCH16W 3.0DT G (130 Hp) specs
|
There is a growing second-hand population of these in the United Kingdom. They are also very popular in New Zealand imported as used vehicles from Japan. The 3 litre turbocharged diesel is especially favoured as its enormous torque but not so impressive power output are ideally suited to the hilly conditions in a country with an overall 100 km/ h speed limit. Many of these vehicles are in commercial passenger service. » Read More About Toyota Granvia |
