1997 Plymouth Voyager III 3.3 AT FWD Ultradrive 7-passenger SE
Plymouth Voyager Problems
Stater
2000, driving down highway car just started
reving up had no power shut off and would not
star...
Coolant leaking from rear of engine
1998, My 1998 Plymouth Voyager 3.0L 6 cylinder
engine is leaking coolant in the rear part of t...
Unknown coolant leak
1999, The engine is a 3.8L 6cyl. It has begun
leaking in some inacessable location that I
can&...
| Body type | Minivan |
|---|---|
| Power | 158 Hp |
| Engine Displacement | 3300 cm3 or 3.3L or 201.3 cu-in |
| Color | gray |
| Transmission Gearbox | Automatic |
| Fuel Type | Gasoline |
| Drive wheel | FF |
| Mileage | 218185 Miles |
| Vin | 2P4FP25B5VR****95 |
| Price (out of date) | $681 |
Frequently Asked Questions | |
|---|---|
| What is the body type, 1997 Plymouth Voyager III? | Minivan, 7 Seats, 4 Doors |
| What is the fuel economy, 1997 Plymouth Voyager 3.3 AT FWD Ultradrive 7-passenger SE? | 11.8 l/100 km |
| How fast is the car, Plymouth Voyager III 1997 Minivan 3.3 AT FWD Ultradrive 7-passenger SE (158 Hp)? | 183 km/h, 0-100 km/h: 11 sec |
| How much power, 1997 Plymouth Voyager Minivan 3.3 AT FWD Ultradrive 7-passenger SE (158 Hp)? | 158 Hp |
| What is the engine size, 1997 Plymouth Voyager III? | 3.3L or 3301cm3 |
| How many gears, What type is the gearbox, 1997 Plymouth Voyager 3.3 AT FWD Ultradrive 7-passenger SE? | Automatic transmission 4 |
| What is the drivetrain, Plymouth Voyager III 1997 Minivan 3.3 AT FWD Ultradrive 7-passenger SE (158 Hp)? | Front |
| How long is this vehicle, 1997 Plymouth Voyager Minivan 3.3 AT FWD Ultradrive 7-passenger SE (158 Hp)? | 4732 mm |
| How wide is the vehicle, 1997 Plymouth Voyager III? | 1905 mm |
| What is the gross weigh, 1997 Plymouth Voyager 3.3 AT FWD Ultradrive 7-passenger SE? | 2270 kg |
| How much trunk (boot) space, Plymouth Voyager III 1997 Minivan 3.3 AT FWD Ultradrive 7-passenger SE (158 Hp)? | 385 l |
Plymouth Voyager III 3.3 AT FWD Ultradrive 7-passenger SE (158 Hp) 1995, 1996, 1997, 1998, 1999, 2000 Specs
General information | |
|---|---|
| Production start year | 1995 |
| Production end year | 2000 |
| Drive type | Front |
| Frame type | Minivan |
| Transmission type | Automatic transmission 4 |
| Engine volume, cc | 3301 |
| 0 to 100 time | 11 |
| Max speed | 183 |
| Clearance, mm | 137 |
| Manufacturing country | USA, Canada |
| Doors | 4 |
Vehicle generation | |
| Generation name | NS |
| Generation number | 3 |
| Production start year | 1995 |
| Production end year | 2000 |
Engine, transmission and steering specs | |
Engine specs | |
| Engine name | EGA |
| Fuel | Petrol (Gasoline) |
| Engine type | V6 |
| Has turbo | no |
| Max power, hp | 158 |
| Max power RPM, rpm | 4850 |
| Max power, hp (kWt) / rpm | 158 (116) / 4850 |
| Max torque, N*m | 275 |
| Max torque RPM, rpm | 3250 |
| Max torque, N*m (kg*m) / rpm | 275 (28) / 3250 |
| Valves per cylinder | 2 |
| Compression ratio | 8.9 |
| Bore, mm | 93 |
| Stroke, mm | 81 |
| Engine additional info | MPI |
Fuel consumption | |
| City | 13.1 |
| Country side | 9.8 |
| Combined | 11.8 |
Transmission | |
| 1st gear ratio | 2.84 |
| 2nd gear ratio | 1.57 |
| 3rd gear ratio | 1 |
| 4th fear ratio | 0.69 |
| Rear gear ratio | 2.21 |
| Main gear ratio | 3.62 |
Steering | |
| Power steering | yes |
| Electric power steering | no |
Battery and alternator | |
| Max generator amper | 90 |
| Battery volume | 66 |
Dimensions | |
Frame dimensions | |
| Exterior length, mm | 4732 |
| Exterior width, mm | 1905 |
| Exterior height, mm | 1740 |
Interior dimensions | |
| Capacity | 7 |
| Seat rows | 3 |
Chassis dimensions | |
| Wheel base, mm | 2878 |
| Turning radius, m | 5.7 |
| Wheel spacing front | 1600 |
| Wheel spacing rear | 1626 |
Weight and permissible load | |
| Mass, kg | 1640 |
| Max capacity | 630 |
| Max. weight | 2270 |
| Trailer max weight wbrakes | 1600 |
Volumes | |
| Fuel tank capacity, l | 76 |
| Trunk volume | 385 |
Other | |
| Aerodynamic drag | 0.35 |
Suspension specs | |
Suspension specs | |
| Front suspension | Independent, Spring McPherson |
| Rear suspension | Dependent, spring loaded |
Wheel rims | |
| Aluminium wheel | option |
| Front wheel disk | 15X6J |
| Rear wheel disk | 15X6J |
Tires | |
| Front wheels | 215/65 R15 |
| Rear wheels | 215/65 R15 |
Brakes | |
| Front brake | Ventilated discs |
| Rear brake | drum brakes |
Exterior | |
Headlights | |
| Halogen headlights | yes |
| Front fog lamps | yes |
| Rear fog lamps | yes |
| Additional stop light | yes |
Side mirrors | |
| Exterior mirrors in body color | no |
| Power adjustable door mirrors | yes |
| Door mirrors heating | yes |
Doors | |
| Side sliding door | yes |
| Sliding doors | option |
| Door handles in body color | no |
Windows | |
| Privacy glass | yes |
| Rear glass heat | option |
Roof | |
| Sunroof | option |
Accessories | |
| Roof rail | option |
| Bumpers | painted in body color |
| Back wiper | yes |
Body color | |
| Metallic paint Body | option |
Interior | |
Steering wheel and center panel | |
| Leather winding | yes |
| Adjustable steering | yes |
| Telescopic steering | no |
| Tilt steering | yes |
| Tachometer | yes |
Interior design | |
| Cloth upholstery | yes |
| Leather upholstery | no |
| Combined obivka Salon | no |
Seats | |
| 2nd row | foldable, backrest is indivisible |
| 3nd row | foldable, backrest is indivisible |
| Removable seats | yes |
| Front bench seat | no |
| Separating armrest front | yes |
| Separating armrest rear | yes |
| Seats pockets | option |
| Mats | yes |
Electric interior package | |
| Power adjustable driver seat | no |
| Power ajustable front seat | no |
| Centralized door lock | option |
| Keyless enter | option |
| Keyless | option |
| Power window front | option |
| Power window rear | option |
Additional interior equipment | |
| Smokers packet | yes |
Safety | |
Airbags | |
| Drivers airbag | yes |
| Passengers airbag | yes |
Active and passive safety | |
| 3 point safety belt | yes |
Electronic security and traffic control systems | |
| ABS | yes |
| Cruise control | yes |
Amenity | |
Microclimate | |
| Air conditioner | option |
| Automatic air conditioning | yes |
| Part climat equipment | no |
Audio systems | |
| Radio | yes |
| Autoreverse casette | yes |
| CD player | option |
| CD changer | option |
| Additional sound equipment | 4 speakers |
Additional amenities | |
| Anti-glare effect | yes |
| Mirrors in sunshields | option |
| Compass | option |
| Onboard computer | option |
Car safety | |
| Immobilizer | no |
Driver Kit | |
| Spare tire | option |
| Spare tyre small | yes |
The Voyager is powered by one of the following engines; a 2.4-liter 4-in-line with 150 hp; a 3.0-liter V-6 with 150 hp; a 3.3-liter V-6 with 158 hp; or a 3.8-liter V-6 with 180 hp. All come with your choice of a 3 or 4-speed automatic and standard ABS. It's available in 2 or 4 wheel drive and sits up to 7 passengers.
1997 Plymouth Voyager III 3.3 AT FWD Ultradrive 7-passenger SE (158 Hp) specs
|
The Grand Voyager minivan was longer than the Voyager in both length and wheelbase, and had more cargo space. In addition, engine choices were different in most years to compensate for the greater weight of the Grand Voyager. Otherwise, the two vehicles were substantially the same. Together with it's nameplate variants, the Dodge Caravan, Chrysler Voyager, Chrysler Town & Country and Volkswagen Routan, the Chrysler minivans have ranked as the 13th bestselling automotive nameplate worldwide, with over 12 million sold. The first Plymouth Voyager was manufactured from 1974-1983 as a rebadged Dodge Sportsman with 12-15 passenger capacity. The Voyager was Plymouth's first truck-bodied vehicle in many decades. This Generation I Voyager minivan used the Chrysler S platform, which was closely related to the K-cars (Plymouth Reliant and Dodge Aries). The Voyager was on Car and Driver magazine's Ten Best list for 1985. A three-speed TorqueFlite automatic transmission and a five-speed manual were available with the four-cylinder engines, including the turbocharged 2.5L engine offered only in 1989 and 1990. » Read More About Plymouth Voyager |
