Body typeMinivan
Power97 Hp
Engine Displacement1500 cm3 or 1.5L or 91.5 cu-in
Transmission GearboxAutomatic
Fuel TypeGasoline
Drive wheelFR or RR
Mileage117439 Miles
Price (out of date)$6228

Frequently Asked Questions

What is the body type, 2008 Toyota Lite Ace VI?Minivan, 5 Seats, 5 Doors
How much power, Toyota Lite Ace Minivan 2008?97 Hp
What is the engine size, Toyota Lite Ace ABF-S402M 2008?1.5L or 1495cm3
How many gears, What type is the gearbox, 2008 Toyota Lite Ace 1.5 GL?Automatic transmission 4
What is the drivetrain, Toyota Lite Ace VI 2008 Minivan 1.5 GL (97 Hp)?Rear
How long is this vehicle, 2008 Toyota Lite Ace Minivan 1.5 GL (97 Hp)?4045 mm
How wide is the vehicle, 2008 Toyota Lite Ace VI?1665 mm

Toyota Lite Ace VI ABF-S402M 1.5 GL (97 Hp) 2008, 2009 Specs

General information

Production start year2008
Production end year2009
Frame typeMinivan
Drive typeRear
Transmission typeAutomatic transmission 4
Engine volume, cc1495
Frame nameABF-S402M
Clearance, mm175
Winter complectationoption
Steering locatonright

Vehicle generation

Generation nameS400
Generation number6
Production start year2008
Production end year2020

Engine, transmission and steering specs

Engine specs

Engine name3SZ-VE
FuelPetrol (Gasoline)
Engine type4 cylinder DOHC
Max power, hp97
Max power RPM, rpm6000
Max power, hp (kWt) / rpm97(71)/6000
Max torque, N*m134
Max torque RPM, rpm4400
Max torque, N*m (kg*m) / rpm134(13.7)/4400
Variable cylinder systemno
Max power, kw (ps) / rpm71?97?/6000
Max torque, N*m (kg*m) / rpm (carsensor)134?13.7?/4400
Start stop systemno

Fuel consumption

Achieve fuel efficiency standards
Fuel consumption (10/15 mode), km/l12.6
Fuel consumption (10/15 mode), l/100km7.93651


Shifter positionOn the dashboard


Power steeringyes
Steereing gear typeGear rail
Steering vgs vgrsno


Frame dimensions

Exterior length, mm4045
Exterior width, mm1665
Exterior height, mm1900
Exterior size (L x W x H), mm4045x1665x1900?mm?

Interior dimensions

Seat rows2
Interior size (L x W x H), mm-x-x-?mm?

Chassis dimensions

Wheel base, mm2650
Front axle length, mm1460
Rear axle length, mm1440
Turning radius, m4.7
Front/rear axis length1460/1440?mm?
Wheel spacing front1460
Wheel spacing rear1440

Weight and permissible load

Mass, kg1230
Total weight2005
Max capacity750


Fuel tank capacity, l43

Suspension specs

Suspension specs

Front suspensionIndependent, Spring McPherson
Rear suspensionDependent, on longitudinal arms
Sport suspensionno
Low downno
Air suspensionno
Cenral diff lockno

Wheel rims

Aluminium wheelno
Magnesium wheelsno


Front wheels165R13LT
Rear wheels165R13LT
Run flat tiresno


Front brakeVentilated discs
Rear brakedrum brakes
Brakes equipment
Brake front search1
Rear brake2



Xenon lampsno
Head lights washerno
Front fog lampsno
Rear fog lampsoption
Rain sensorno

Side mirrors

autocorrected mirrorsno


Side sliding doorno
Sliding doorsyes
Sliding electric doorno
Sliding electric doorsno
Door easy closerno
Power rear doorno


Privacy glassno
Ultraviolet glass protectionno


Big sunroofno
T bar roofno
Roof equipment
Targa roofno
Hard topno
Soft topno
Metal topno
Canvas topno


Roof railno
Front spoilerno
Rear spoilerno

Body color

Colors2508 1300


Steering wheel and center panel

Engine start buttonno

Interior design

Leather seatno
Antibacterial repellentno


Bucket seatno
2nd rowfoldable, backrest is indivisible
3nd rowno
Seat lifterno
Full flat seats
Removable seatsno
Ottoman seatno
Front bench seatno
Walk throughtno
2nd row throughtno

Electric interior package

Power adjustable driver seatno
Power ajustable front seatno
Adjustable 3rd rowno
Front seat heaterno
Rear seats heaterno
Seat position memoryno
Keyless enteryes
Power windowyes
Stearing wheel heaterno

Additional interior equipment

AC plugno



Drivers airbagyes
Passengers airbagyes
Side airbagno
Curtain airbagsno
2 airbagsno

Children safety

isofix barno
Build-in child seatno

Active and passive safety

Active headrestno
Road Service

Electronic security and traffic control systems

ABSABS? standard ?
Break assistno
traction controlno
Down hill assistno
Lane Keep Assistno
Cruise controlno
Distance control systemno
Intelligent AFSno
Night visionno
Intelligent parking assistno
Collision mitigation systemno



Air conditionermanualair conditioning(standard)
Air purifierno
Air filterno
Odor absorberno

Audio systems

Autoreverse casetteno
CD playerno
MD palyerno
Audio HDDno
Rear entertainment systemno
Additional sound equipment

Navigation and video equipment

Full color LCD display
Navigation system
Optional navigation systemno
Traffic jam assistno
Parking assist systemno
Front monitorno
Sides monitorsno
Back monitorno

Additional amenities

Lagage boxno

Car safety

Alarm systemno
Security alarmno

2008 Toyota Lite Ace VI ABF-S402M 1.5 GL (97 Hp) specs

The Toyota Liteace is a line of motor vehicles produced by the Japanese manufacturer Toyota. Launched in 1970, the Liteace is a medium-sized van commonly distributed to Asia, Australia and Africa for personal or commercial use.

The Liteace was marketed in two different forms:

  • A box-like and more angular design, similar to a Nissan C22 (Vanette).
  • A more MPV-like design, with design cues of the Toyota Hiace.

The Toyota Liteace Noah, an MPV replaced by the Toyota Noah, was also released.

In 2008, a new model based on the Daihatsu Gran Max which launch in Indonesia in late 2007 replace the Toyota LiteAce along with Toyota TownAce in Japan. Both truck and van type are available in 1.5L engine.
