| Body type | Hatchback |
|---|---|
| Power | 50 Hp |
| Engine Displacement | 700 cm3 or 0.7L or 42.7 cu-in |
| Transmission Gearbox | Manual |
| Fuel Type | Gasoline |
| Drive wheel | 4WD |
| Vin | U62V1****97 |
| Price (out of date) | $3426 |
Frequently Asked Questions | |
|---|---|
| What is the body type, 2009 Mitsubishi Minica VIII? | Hatchback, 4 Seats, 3 Doors |
| How much power, Mitsubishi Minica Hatchback 2009? | 50 Hp |
| What is the engine size, Mitsubishi Minica HBD-H47V 2009? | 0.7L or 657cm3 |
| How many gears, What type is the gearbox, 2009 Mitsubishi Minica 660 Lyra 4WD? | 5 speed Manual |
| What is the drivetrain, Mitsubishi Minica VIII 2009 Hatchback 660 Lyra 4WD (50 Hp)? | All wheel drive (4x4) |
| How long is this vehicle, 2009 Mitsubishi Minica Hatchback 660 Lyra 4WD (50 Hp)? | 3395 mm |
| How wide is the vehicle, 2009 Mitsubishi Minica VIII? | 1475 mm |
Mitsubishi Minica VIII HBD-H47V 660 Lyra 4WD (50 Hp) 2006, 2007, 2008, 2009 Specs
General information | |
|---|---|
| Production start year | 2006 |
| Production end year | 2009 |
| Drive type | All wheel drive (4x4) |
| Frame type | Hatchback |
| Transmission type | 5 speed Manual |
| Engine volume, cc | 657 |
| Frame name | HBD-H47V |
| Clearance, mm | 160 |
| Manufacturing country | Japan |
| Doors | 3 |
| Winter complectation | yes |
| Steering locaton | right |
Engine, transmission and steering specs | |
Engine specs | |
| Engine name | 3G83 |
| Fuel | Petrol (Gasoline) |
| Engine type | 3 cylinder SOHC |
| Max power, hp | 50 |
| Max power RPM, rpm | 6500 |
| Max power, hp (kWt) / rpm | 50(37)/6500 |
| Max torque, N*m | 62 |
| Max torque RPM, rpm | 4000 |
| Max torque, N*m (kg*m) / rpm | 62 (6.3) / 4000 |
| Eco type | 2005 emission regulation 75% reduction |
| Variable cylinder system | no |
| Max power, kw (ps) / rpm | 37?50?/6500 |
| Max torque, N*m (kg*m) / rpm (carsensor) | 62?6.3?/4000 |
| Start stop system | no |
Fuel consumption | |
| Fuel consumption (10/15 mode), km/l | 19.2 |
| Fuel consumption (10/15 mode), l/100km | 5.2 |
Transmission | |
| Shifter position | On the floor. |
Steering | |
| Power steering | yes |
| Steereing gear type | Gear rail |
| Steering vgs vgrs | no |
Dimensions | |
Frame dimensions | |
| Exterior length, mm | 3395 |
| Exterior width, mm | 1475 |
| Exterior height, mm | 1510 |
| Exterior size (L x W x H), mm | 3395x1475x1510?mm? |
Interior dimensions | |
| Capacity | 4 |
| Seat rows | 2 |
| Interior size (L x W x H), mm | -x-x-?mm? |
Chassis dimensions | |
| Wheel base, mm | 2340 |
| Front axle length, mm | 1300 |
| Rear axle length, mm | 1295 |
| Turning radius, m | 4.4 |
| Front/rear axis length | 1300/1295?mm? |
| Wheel spacing front | 1300 |
| Wheel spacing rear | 1295 |
Weight and permissible load | |
| Mass, kg | 730 |
| Max capacity | 200 |
Volumes | |
| Fuel tank capacity, l | 30 |
Suspension specs | |
Suspension specs | |
| Front suspension | Independent, Spring McPherson |
| Rear suspension | Dependent, on longitudinal arms |
| Sport suspension | no |
| Low down | no |
| Air suspension | no |
| Cenral diff lock | no |
| LSD | no |
| 4ws | no |
Wheel rims | |
| Aluminium wheel | no |
| Magnesium wheels | no |
Tires | |
| Front wheels | 145/80R12 |
| Rear wheels | 145/80R12 |
| Run flat tires | no |
Brakes | |
| Front brake | Discs |
| Rear brake | drum brakes |
| Brakes equipment | no |
| Brake front search | 1 |
| Rear brake | 2 |
Exterior | |
Headlights | |
| Xenon lamps | no |
| Head lights washer | no |
| Front fog lamps | no |
| Rear fog lamps | no |
| Rain sensor | no |
Side mirrors | |
| autocorrected mirrors | no |
Doors | |
| Side sliding door | no |
| Sliding doors | no |
| Sliding electric door | no |
| Sliding electric doors | no |
| Door easy closer | no |
| Power rear door | no |
Windows | |
| Privacy glass | no |
| Ultraviolet glass protection | yes |
Roof | |
| Sunroof | no |
| Big sunroof | no |
| T bar roof | no |
| Roof equipment | no |
| Targa roof | no |
| Hard top | no |
| Soft top | no |
| Metal top | no |
| Canvas top | no |
Accessories | |
| Roof rail | no |
| Front spoiler | no |
| Rear spoiler | no |
Body color | |
| Colors | 149 1213 2887 1214 |
Interior | |
Steering wheel and center panel | |
| Engine start button | no |
Interior design | |
| Water-repellent | no |
| Leather seat | no |
| Antibacterial repellent | no |
Seats | |
| Bucket seat | no |
| 2nd row | foldable, backrest is indivisible |
| 3nd row | no |
| Seat lifter | no |
| Full flat seats | no |
| Removable seats | no |
| Ottoman seat | no |
| Front bench seat | no |
| Walk throught | no |
| 2nd row throught | no |
Electric interior package | |
| Power adjustable driver seat | no |
| Power ajustable front seat | no |
| Adjustable 3rd row | no |
| Front seat heater | yes |
| Rear seats heater | no |
| Seat position memory | no |
| Keyless enter | no |
| Power window | option |
| Stearing wheel heater | no |
Additional interior equipment | |
| AC plug | no |
Safety | |
Airbags | |
| Drivers airbag | option |
| Passengers airbag | option |
| Side airbag | no |
| Curtain airbags | no |
| 2 airbags | no |
Children safety | |
| isofix bar | no |
| Build-in child seat | no |
Active and passive safety | |
| Active headrest | no |
| Road Service | |
Electronic security and traffic control systems | |
| ABS | ABS with EBD ? option ? |
| Break assist | no |
| ESP | no |
| traction control | no |
| Down hill assist | no |
| AYC | no |
| SH-4WD | no |
| Lane Keep Assist | no |
| Cruise control | no |
| Distance control system | no |
| Intelligent AFS | no |
| Night vision | no |
| Parktronic | no |
| Intelligent parking assist | no |
| Collision mitigation system | no |
Amenity | |
Microclimate | |
| Air conditioner | yes |
| Air purifier | no |
| Humidifier | no |
| Air filter | no |
| Odor absorber | no |
Audio systems | |
| Radio | option |
| Autoreverse casette | no |
| CD player | option |
| DVD-audio | no |
| MD palyer | no |
| Audio HDD | no |
| Speaker | yes |
| Rear entertainment system | no |
Navigation and video equipment | |
| Full color LCD display | no |
| Navigation system | no |
| Optional navigation system | no |
| Traffic jam assist | no |
| Parking assist system | no |
| Front monitor | no |
| Sides monitors | no |
| Back monitor | no |
Additional amenities | |
| Lagage box | no |
| Etc | no |
Car safety | |
| Alarm system | no |
| Security alarm | no |
2009 Mitsubishi Minica VIII HBD-H47V 660 Lyra 4WD (50 Hp) specs
|
The precursor of the Minica was the Mitsubishi 360, a series of vans and Kei trucks introduced in 1961. Designed for the lowest kei car vehicle tax classification, it was powered by a 356cc engine producing 17PS (17hp/ 13kW). After the successful introduction of the Minica, the 360 continued alongside until 1966. The first Minica was first introduced as a two-door sedan based on the Mitsubishi 360, with a front-mounted ME21 359cc twin cylinder two stroke air-cooled engine driving the rear wheels, transverse leaf springs in front and beam axle/ leaf springs at the rear. In 1966, the Mitsubishi Minicab cab-over pickup truck was launched to replace the Mitsubishi 360. Powered by the same air cooled two-stroke 359cc engine as the Minica, it came with cargo gates on three sides to simplify loading and unloading. The second generation Minica was introduced in July 1969 with a three-door sedan body, 359cc OHV engine and coil springs front and rear. Two 2G21 SOHC water-cooled powerplants were optionally available, the Red 28hp (21kW) engine and the Gold engine fitted with twin SU carburetors developing 38hp (28kW), which was fitted as standard to the GSS sport model. A two-door wagon body was added in December, which would remain in production until the fourth generation in the early 1980s. » Read More About Mitsubishi Minica |
