Mitsubishi eK Wagon III DBA-B11W 660 M e-Assist (49 Hp) 2017, 2018 Specs

General information

Production start year2017
Production end year2018
Drive typeFront
Frame typeHatchback
Transmission typeVariator
Engine volume, cc659
Frame nameDBA-B11W
Clearance, mm150
Manufacturing countryJapan
Doors5
Winter complectationyes
Steering locatonright

Engine, transmission and steering specs

Engine specs

Engine name3B20
FuelPetrol (Gasoline)
Engine type3 cylinder DOHC
Max power, hp49
Max power RPM, rpm6500
Max power, hp (kWt) / rpm49 (36) / 6500
Max torque, N*m56
Max torque RPM, rpm5500
Max torque, N*m (kg*m) / rpm56 (6) / 5500
Valves per cylinder4
Compression ratio12
Bore, mm65.4
Stroke, mm65.4
Engine additional infoECI-MULTI
Eco type2005 emission regulation 75% reduction
Start stop systemyes

Fuel consumption

Achieve fuel efficiency standardsCompliance with the 2020 fuel consumption standard
Combined3.9
Co2 emission90

Transmission

Range gear ratio4.007 - 0.550
Rear gear ratio3.771
Main gear ratio4.575
Shifter positionOn the dashboard

Steering

Electric power steeringyes
Steereing gear typeGear rail

Dimensions

Frame dimensions

Exterior length, mm3395
Exterior width, mm1475
Exterior height, mm1620

Interior dimensions

Capacity4
Seat rows2
Interior length, mm2085
Interior width, mm1295
Interior height, mm1280

Chassis dimensions

Wheel base, mm2430
Front axle length, mm1300
Rear axle length, mm1290
Turning radius, m4.4
Wheel spacing front1300
Wheel spacing rear1290

Weight and permissible load

Mass, kg840

Volumes

Fuel tank capacity, l30

Suspension specs

Suspension specs

Front stabilizeryes
Front suspensionIndependent, Spring McPherson
Rear suspensionDependent, on longitudinal arms

Wheel rims

Aluminium wheelno

Tires

Front wheels155/65R14
Rear wheels155/65R14

Brakes

Front brakeDiscs
Rear brakedrum brakes
Regenerative brakingyes

Exterior

Headlights

Halogen headlightsyes
Xenon lampsno
Led backlightsyes
Additional stop lightyes
Light sensorno

Side mirrors

Exterior mirrors in body coloryes
Side mirrors with repeaters indicatorsno
Power adjustable door mirrorsyes
Door mirrors heatingyes

Doors

Door handles in body coloryes

Windows

Privacy glassyes
Ultraviolet glass protectionyes
Rear glass heatyes

Accessories

Back wiperyes

Interior

Steering wheel and center panel

Leather windingoption
Tilt steeringyes
Audio control on steering wheelno
Tachometeroption
Env tempyes
Engine start buttonno

Interior design

Cloth upholsteryyes

Seats

2nd row50/50 ratio fold seat
Seat lifteryes
Front bench seatyes
Separating armrest frontyes
Seats pocketsyes

Electric interior package

Front seat heateryes
Centralized door lockyes
Keyless enteryes
Keylessno
Power window frontyes
Power window rearyes

Additional interior equipment

Holders for bottles in doorsyes

Safety

Airbags

Drivers airbagyes
Passengers airbagyes

Children safety

isofix baryes

Electronic security and traffic control systems

ABSyes
Electronic Brake Distributionyes
Break assistyes
Automatic activation of alarm in emergency brakingyes
ESPyes
traction controlyes
Hill-start assist control systemyes
Lane Keep Assistno
Cruise controlno
Control system of a headlightno
Collision mitigation systemyes

Amenity

Microclimate

Air conditioneryes
Automatic air conditioningyes
Air filteryes

Audio systems

Additional sound equipmentaudio equipment, 2 speakers

Navigation and video equipment

Parking assist systemno
Front monitorno
Sides monitorsno
Back monitorno

Additional amenities

Antidazzle rearview mirrorno
Mirrors in sunshieldsyes
Lagage boxyes

Car safety

Alarm systemno


2017 Mitsubishi eK Wagon III DBA-B11W 660 M e-Assist (49 Hp) specs

The Mitsubishi eK is a Japanese kei car from Mitsubishi Motors, based on the long-running Mitsubishi Minica, and first introduced on October 11, 2001 at ¥910,000 to ¥1,108,000. According to the company the name stands for "excellent Keijidōsha", or "excellent minicar". It was available either as an eK Wagon (introduced October 2001), eK Sport (September 2002), eK Classy (May 2003) or eK Active (May 2004). The range was given a styling revision and re-released on September 13, 2006, priced from ¥913,500 to ¥1,484,700.


Immediately upon its release it was the recipient of the "Good Design Award" by the Japanese Ministry of Economy, Trade and Industry in 2001. While the initial sales target was 10,000 units per month, it sold 13,000 in its first four days, and 20,000 by the end of October 2001. It is Mitsubishi's highest volume model in the Japanese domestic market, and total sales to 2005 are approximately 480,000. Since 2005, Nissan Motors has received 36,000 eK wagons annually from Mitsubishi, to be sold within the domestic market as the Nissan Otti.

  • Engine
Type: 3G83 SOHC 12v straight-3 Capacity: 657cc Compression ratio: 10.2:1 (naturally aspirated) 8.5:1 (turbocharged) Peak power: 37kW (50PS) at 6500rpm (n/ a) 47kW (64PS) at 6000rpm (turbo) Peak torque: 62N·m (46ft·lbf) at 4000rpm (n/ a) 93N·m (69ft·lbf) at 3500rpm (turbo)
  • Suspension
Front: MacPherson struts Rear: 3-link torque arm type
  • Tyres
155/ 65R13 (Wagon) 165/ 55R14 (Sport)
  • Turning circle: 4.4m
  • Seats: 4
