1992 Mazda Proceed Marvie 2.6 Marvie


1992 Mazda Proceed Marvie E-UV66R 2.6 Marvie (120 Hp)
Proceed Marvie E-UV66R 2.6 Marvie (120 Hp)
1992 Proceed Marvie E-UV66R 2.6 Marvie (120 Hp)
Mazda Proceed Marvie E-UV66R 2.6 Marvie (120 Hp)
1992 Mazda Proceed Marvie E-UV66R 2.6 Marvie (120 Hp)
Proceed Marvie E-UV66R 2.6 Marvie (120 Hp)
1992 Proceed Marvie E-UV66R 2.6 Marvie (120 Hp)

More photos of Mazda Proceed Marvie

Mazda Proceed Marvie Problems
Over heating
1997, 1.The car is overheating. The radiator
is OK, the coolant is there, the hoses are OK a...
Clutch
1994, need to know wher to put fluid for
steerung and if you can use power steering
fluid inst...
Mazda proceed G6 camshaft timing.
1992, I need to know how to align cam sprocket
timing mark when engine is at T D C VEHICLE has...

Body typeSUV
Power120 Hp
Engine Displacement2600 cm3 or 2.6L or 158.6 cu-in
Colorgray
Transmission GearboxAutomatic
Fuel TypeGasoline
Drive wheel4WD
Mileage42874 Miles
VinUV66R-****32
Price (out of date)$4894

Frequently Asked Questions

What is the body type, Mazda Proceed Marvie SUV 1992?SUV, 7 Seats, 5 Doors
How much power, Mazda Proceed Marvie E-UV66R 1992?120 Hp
What is the engine size, 1992 Mazda Proceed Marvie 2.6 Marvie?2.6L or 2605cm3
How many gears, What type is the gearbox, Mazda Proceed Marvie 1992 SUV 2.6 Marvie (120 Hp)?Automatic transmission 4
What is the drivetrain, 1992 Mazda Proceed Marvie SUV 2.6 Marvie (120 Hp)?All wheel drive (4x4)
How long is this vehicle, Mazda Proceed Marvie SUV 1992?4950 mm
How wide is the vehicle, Mazda Proceed Marvie E-UV66R 1992?1720 mm

Mazda Proceed Marvie E-UV66R 2.6 Marvie (120 Hp) 1992, 1993, 1994, 1995, 1996 Specs

General information

Complectation name2.6 Marvie
Production start year1992
Production end year1996
Price of new car in Tokyo, yen2457000
Drive typeAll wheel drive (4x4)
Frame typeSUV
Transmission typeAutomatic transmission 4
Engine volume, cc2605
Frame nameE-UV66R
Clearance, mm210
Manufacturing countryJapan
Doors5
Right hand driveyes
Left hand driveno

Vehicle generation

Generation nameUV
Generation number1
Production start year1991
Production end year1996

Engine, transmission and steering specs

Engine specs

Engine nameG6
FuelPetrol (Gasoline)
Engine typeIn-line, 4-cylinder
Has turbono
Max power, hp120
Max power RPM, rpm4500
Max power, hp (kWt) / rpm120 (88) / 4500
Max torque, N*m202
Max torque RPM, rpm3500
Max torque, N*m (kg*m) / rpm202 (21) / 3500
Compression ratio8.4
Bore, mm92
Stroke, mm98
Actuator valvesSOHC

Fuel consumption

Fuel consumption (10/15 mode), l/100km13.9
Fuel consumption (60 km/h mode), l/100km8.3

Transmission

1st gear ratio2.786
2nd gear ratio1.546
3rd gear ratio1
4th fear ratio0.694
Rear gear ratio2.272

Steering

Power steeringyes

Dimensions

Frame dimensions

Exterior length, mm4950
Exterior width, mm1720
Exterior height, mm1800

Interior dimensions

Capacity7
Seat rows3
Interior length, mm2750
Interior width, mm1400
Interior height, mm1135

Chassis dimensions

Wheel base, mm3000
Front axle length, mm1440
Rear axle length, mm1430
Turning radius, m6.4
Wheel spacing front1480
Wheel spacing rear1470

Weight and permissible load

Mass, kg2175

Volumes

Fuel tank capacity, l56

Other

Remarks (temporary)Information of fuel consumption in mode \"10-15\" is not available as they were absent in the sale documents. Therefore data for mode \"10\" were inserted.

Suspension specs

Suspension specs

Front stabilizeryes
Front suspensionIndependent on double wishbones
Rear stablilizerno
Rear suspensionDependent, spring loaded
LSDno

Wheel rims

Aluminium wheelno

Tires

Front wheels225/80R15
Rear wheels225/80R15

Brakes

Front brakeDiscs
Rear brakedrum brakes
Brake front search1
Rear brake2

Exterior

Headlights

Xenon lampsno
Front fog lampsno
Rear fog lampsno
Additional stop lightno
Cornering lampsno

Side mirrors

Power adjustable door mirrorsno

Windows

Ultraviolet glass protectionno

Roof

Sunroofyes
Tilt sunroofno
Twin sunroofno

Accessories

Roof railyes
Front spoilerno
Rear spoilerno
Back wiperyes

Body color

Colors2 20 12

Interior

Steering wheel and center panel

Leather windingno
Telescopic steeringno
Tilt steeringyes
Tachometeryes

Interior design

Leather seatno
Wood panelno

Seats

Reclining seatsno
Removable seatsno
Turning seatsno

Electric interior package

Power adjustable driver seatno
Power ajustable front seatno
Power ajustable back seatno
Centralized door lockyes
Keyless enterno
Power windowyes
Central power window controlno

Safety

Airbags

Drivers airbagno
Passengers airbagno
Side airbagno

Children safety

Child car restraintsyes

Active and passive safety

Durable frameno
Side impact barno
3 point safety beltyes
Safety belt pretensionerno
Safety belt limiterno

Electronic security and traffic control systems

Break assistno
traction controlno
Cruise controlno

Amenity

Microclimate

Coolerno
Automatic air conditioningno
Twin conditioning systemno
Air purifierno

Audio systems

Radioyes
Autoreverse casetteyes
CD playerno
CD changerno
MD palyerno
MD changerno

Navigation and video equipment

Parking assist systemno


1992 Mazda Proceed Marvie E-UV66R 2.6 Marvie (120 Hp) specs

See Mazda B-Series (North America) for that market's version

The Mazda B-series is a 2-door pick-up truck, first manufactured in 1961 by Mazda Motor Corporation. The current model, which was first manufactured in 1999, is the mark 7. The mark 7 can be manufactured with 1 of four body styles and 1 of two engines.


From the first B-Series pickup truck, Mazda has used the engine displacement to determine the name. Thus, the B1500 had a 1.5L engine, and the new B4000 has a 4.0L V6. In Japan, Mazda used the Proceed name on its compact pickup trucks, and another line of larger trucks is available called the Mazda Titan. Other names used for this line include Mazda Bravo (Australia), Mazda Bounty (New Zealand), Mazda Magnum / Thunder / Fighter (Thailand), and Mazda Drifter (South Africa).

Mazda's partnership with Ford has resulted in the sharing of this vehicle—the Mazda B-Series and Ford Ranger are essentially the same. In Australia and New Zealand, since the 1970s, the Ford Courier name is also used and the line continues today.

However, it should be borne in mind that the Mazda B-Series and Ford Ranger twins found inside North America are unrelated to the ones sold elsewhere. These are engineered by Mazda, whereas the North American models are developed by Ford. See Mazda B-Series for more information on the variations on the B-Series line.
