1991 Mazda Carol II 660 F
Mazda Carol Problems
Engen problem
2003, the problem is that carol mazda car will
lose the lanth it mean that mazda car will open...
| Body type | Hatchback 3 Doors |
|---|---|
| Power | 42 Hp |
| Engine Displacement | 700 cm3 or 0.7L or 42.7 cu-in |
| Color | blue |
| Transmission Gearbox | Automatic |
| Fuel Type | Gasoline |
| Drive wheel | FF |
| Vin | AA6PA****06 |
| Price (out of date) | $811 |
Frequently Asked Questions | |
|---|---|
| What is the body type, 1991 Mazda Carol II? | Hatchback, 4 Seats, 3 Doors |
| How much power, Mazda Carol Hatchback 1991? | 42 Hp |
| What is the engine size, Mazda Carol E-AA6PA 1991? | 0.7L or 657cm3 |
| How many gears, What type is the gearbox, 1991 Mazda Carol 660 F? | Automatic transmission 3 |
| What is the drivetrain, Mazda Carol II 1991 Hatchback 660 F (42 Hp)? | Front |
| How long is this vehicle, 1991 Mazda Carol Hatchback 660 F (42 Hp)? | 3250 mm |
| How wide is the vehicle, 1991 Mazda Carol II? | 1395 mm |
Mazda Carol II E-AA6PA 660 F (42 Hp) 1990, 1991 Specs
General information | |
|---|---|
| Complectation name | 660 F |
| Production start year | 1990 |
| Production end year | 1991 |
| Price of new car in Tokyo, yen | 703000 |
| Drive type | Front |
| Frame type | Hatchback |
| Transmission type | Automatic transmission 3 |
| Engine volume, cc | 657 |
| Frame name | E-AA6PA |
| Clearance, mm | 150 |
| Manufacturing country | Japan |
| Doors | 3 |
| Right hand drive | yes |
| Left hand drive | no |
Vehicle generation | |
| Generation name | Mk 2 |
| Generation number | 2 |
| Production start year | 1989 |
| Production end year | 1995 |
Engine, transmission and steering specs | |
Engine specs | |
| Engine name | F6A |
| Fuel | Petrol (Gasoline) |
| Engine type | water cooling 3 cylinder SOHC12 valve |
| Has turbo | no |
| Max power, hp | 42 |
| Max power RPM, rpm | 6500 |
| Max power, hp (kWt) / rpm | 42 (31) / 6500 |
| Max torque, N*m | 52 |
| Max torque RPM, rpm | 4000 |
| Max torque, N*m (kg*m) / rpm | 52 (5) / 4000 |
| Compression ratio | 10 |
| Bore, mm | 65 |
| Stroke, mm | 66 |
Fuel consumption | |
| Fuel consumption (10/15 mode), l/100km | 6.2 |
| Fuel consumption (60 km/h mode), l/100km | 3.8 |
Transmission | |
| 1st gear ratio | 2.659 |
| 2nd gear ratio | 1.53 |
| 3rd gear ratio | 1 |
| Rear gear ratio | 2.129 |
Steering | |
| Power steering | option |
Dimensions | |
Frame dimensions | |
| Exterior length, mm | 3250 |
| Exterior width, mm | 1395 |
| Exterior height, mm | 1415 |
Interior dimensions | |
| Capacity | 4 |
| Seat rows | 2 |
| Interior length, mm | 1650 |
| Interior width, mm | 1210 |
| Interior height, mm | 1195 |
Chassis dimensions | |
| Wheel base, mm | 2335 |
| Front axle length, mm | 1220 |
| Rear axle length, mm | 1200 |
| Turning radius, m | 4.4 |
| Wheel spacing front | 1220 |
| Wheel spacing rear | 1200 |
Weight and permissible load | |
| Mass, kg | 590 |
Volumes | |
| Fuel tank capacity, l | 30 |
Other | |
| Remarks (temporary) | Information of fuel consumption in mode \"10-15\" is not available as they were absent in the sale documents. Therefore data for mode \"10\" were inserted. |
Suspension specs | |
Suspension specs | |
| Front stabilizer | yes |
| Front suspension | Independent, Spring McPherson |
| Rear stablilizer | no |
| Rear suspension | Dependent, on longitudinal arms |
| LSD | no |
Wheel rims | |
| Aluminium wheel | option |
Tires | |
| Front wheels | 135SR12 |
| Rear wheels | 135SR12 |
Brakes | |
| Front brake | Discs |
| Rear brake | drum brakes |
| Brake front search | 1 |
| Rear brake | 2 |
Exterior | |
Headlights | |
| Xenon lamps | no |
| Front fog lamps | no |
| Rear fog lamps | no |
| Additional stop light | no |
| Cornering lamps | no |
Side mirrors | |
| Power adjustable door mirrors | no |
Windows | |
| Ultraviolet glass protection | no |
Roof | |
| Sunroof | no |
| Tilt sunroof | no |
| Twin sunroof | no |
Accessories | |
| Roof rail | no |
| Front spoiler | no |
| Rear spoiler | no |
| Back wiper | option |
Body color | |
| Colors | 7 2 25 8 12 |
Interior | |
Steering wheel and center panel | |
| Leather winding | no |
| Telescopic steering | no |
| Tilt steering | no |
| Tachometer | no |
Interior design | |
| Leather seat | no |
| Wood panel | no |
Seats | |
| Reclining seats | no |
| Removable seats | no |
| Turning seats | no |
Electric interior package | |
| Power adjustable driver seat | no |
| Power ajustable front seat | no |
| Power ajustable back seat | no |
| Centralized door lock | no |
| Keyless enter | no |
| Power window | no |
| Central power window control | no |
Safety | |
Airbags | |
| Drivers airbag | no |
| Passengers airbag | no |
| Side airbag | no |
Children safety | |
| Child car restraints | no |
Active and passive safety | |
| Durable frame | no |
| Side impact bar | no |
| 3 point safety belt | no |
| Safety belt pretensioner | no |
| Safety belt limiter | no |
Electronic security and traffic control systems | |
| Break assist | no |
| traction control | no |
| Cruise control | no |
Amenity | |
Microclimate | |
| Cooler | no |
| Automatic air conditioning | no |
| Twin conditioning system | no |
| Air purifier | no |
Audio systems | |
| Radio | option |
| Autoreverse casette | option |
| CD player | no |
| CD changer | no |
| MD palyer | no |
| MD changer | no |
Navigation and video equipment | |
| Parking assist system | no |
1991 Mazda Carol II E-AA6PA 660 F (42 Hp) specs
|
The Carol 600 appeared in the fall of 1962 with a larger 586 cc OHV engine and a longer 320 cm length. It was available as a 4-door sedan in late 1963. The car was called the 'Carol' in Japan, and the '600', 'P600', and 'N600' in other markets. The Chantez (or Chante) had a longer wheelbase at 220 cm than most of its competitors and boasted the powerful 2-stroke engine from the Porter. Sales halted in 1977, and Mazda did not produce another kei car until 1989. The Carol name appeared again in 1989 on the Autozam Carol. The Carol was produced for Mazda by Suzuki, and while it used the Suzuki Alto's platform, its interior and exterior were completely unique to Mazda. It was a front or all-wheel drive kei car with a SOHC 547 cc 3-cylinder F5B engine and a 233 cm wheelbase. New regulations brought about the replacement of the 1989 Carol within 4 months. The new car was 6 cm longer and used a larger 657 cc F6A engine. In 1991, Mazda offered a turbocharged engine, and the car was lengthened to 329 cm in 1992. » Read More About Mazda Carol |
