Body typeSUV 3 Doors
Power96 Hp
Engine Displacement2300 cm3 or 2.3L or 140.3 cu-in
Transmission GearboxManual
Fuel TypeGasoline
Drive wheel4WD
Mileage62758 Miles
Price (out of date)$13114

Frequently Asked Questions

What is the body type, Isuzu Trooper SUV 1990?SUV, 5 Seats, 3 Doors
How fast is the car, Isuzu Trooper UBS17FLK 1990?155 km/h
How much power, 1990 Isuzu Trooper 2.3 MT DLX?96 Hp
What is the engine size, Isuzu Trooper 1990 SUV 2.3 MT DLX (96 Hp)?2.3L or 2254cm3
How many gears, What type is the gearbox, 1990 Isuzu Trooper SUV 2.3 MT DLX (96 Hp)?5 speed Manual
What is the drivetrain, Isuzu Trooper SUV 1990?All wheel drive (4x4)
How long is this vehicle, Isuzu Trooper UBS17FLK 1990?4470 mm
How wide is the vehicle, 1990 Isuzu Trooper 2.3 MT DLX?1650 mm
What is the gross weigh, Isuzu Trooper 1990 SUV 2.3 MT DLX (96 Hp)?2085 kg

Isuzu Trooper UBS17FLK 2.3 MT DLX (96 Hp) 1987, 1988, 1989, 1990, 1991 Specs

General information

Production start year1987
Production end year1991
Drive typeAll wheel drive (4x4)
Frame typeSUV
Transmission type5 speed Manual
Frame nameUBS17FLK
Max speed155
Clearance, mm210
Manufacturing countryJapan

Engine, transmission and steering specs

Engine specs

Engine name4ZD1
FuelPetrol (Gasoline)
Engine typeIn-line, 4-cylinder
Has turbono
Max power, hp96
Max power RPM, rpm4600
Max power, hp (kWt) / rpm96 (71) / 4600
Max torque, N*m123
Max torque RPM, rpm2600
Max torque, N*m (kg*m) / rpm123 (13) / 2600
Valves per cylinder2
Compression ratio8.3
Bore, mm89.3
Stroke, mm90


1st gear ratio3.767
2nd gear ratio2.314
3rd gear ratio1.404
4th fear ratio1
5th gear ratio0.809
Rear gear ratio3.873
Main gear ratio4.555


Power steeringyes


Frame dimensions

Exterior length, mm4470
Exterior width, mm1650
Exterior height, mm1800

Interior dimensions

Seat rows2

Chassis dimensions

Wheel base, mm2650
Wheel spacing front1390
Wheel spacing rear1400

Weight and permissible load

Mass, kg1585
Max capacity500
Max. weight2085
Trailer max weight wobrakes750
Trailer max weight wbrakes3000


Fuel tank capacity, l83

Suspension specs

Suspension specs

Front stabilizeryes
Front suspensionIndependent on double wishbones
Rear stablilizerno
Rear suspensionDependent, spring loaded

Wheel rims

Aluminium wheeloption
Front wheel disk16x6J
Rear wheel disk16x6J


Front wheels225/75 R15
Rear wheels225/75 R15


Front brakeVentilated discs
Rear brakeVentilated discs



Halogen headlightsyes
Head lights washerno
Front fog lampsyes
Rear fog lampsyes

Side mirrors

Exterior mirrors in body colorno
Power adjustable door mirrorsno
Door mirrors heatingno


Chrome door handlesoption


Privacy glassyes
Rear glass heatoption


Tilt sunroofno


Back wiperoption
Rear mudflapsyes

Body color

Metallic paint Bodyoption


Steering wheel and center panel

Leather windingoption
Adjustable steeringoption
Env tempno

Interior design

Cloth upholsteryyes
Leather upholsteryno


Front seats ajustin 4 directions
2nd row60/40 ratio fold seat
Separating armrest frontoption
Separating armrest rearno

Electric interior package

Power ajustable front seatno
Front seat heateroption
Rear seats heaterno
Centralized door lockoption
Keyless enterno
Power window frontoption
Power window rearoption



Drivers airbagno
Passengers airbagno

Active and passive safety

3 point safety beltyes
Safety belt pretensioneryes

Electronic security and traffic control systems

Cruise controlno



Air conditioneroption
Automatic air conditioningno
Air filterno

Audio systems

Autoreverse casetteyes
CD playerno
CD changerno

Additional amenities

Onboard computerno

Car safety

Security alarmno

Driver Kit

Spare tireyes

The Trooper, slightly restyled in 98 comes powered by a 3.5-liter DOHC 24-valve V-6 with 215 hp and a choice of a 5-speed manual or 4-speed automatic transmission. It is only available with 4 wheel drive.

1990 Isuzu Trooper UBS17FLK 2.3 MT DLX (96 Hp) specs

The Isuzu Trooper is a mid-size SUV produced by the Japanese automaker Isuzu between 1981 and 2002. It was exported worldwide as the Isuzu Bighorn, Subaru Bighorn, Isuzu Trooper, Honda Horizon, Acura SLX, Chevrolet Trooper, Opel/ Vauxhall Monterey, Holden Jackaroo and Holden Monterey. It was a huge seller in the sport utility vehicle segment.

There were two generations of the Trooper produced – the first spanning 1981 through 1991, and the second from 1992 through 2002 when Isuzu ceased export of the model. It began its production run being somewhat primitive and underpowered, offered only with a 4 cylinder motor, standard 5 speed manual transmission, and part-time four-wheel drive system. As the first generation progressed, it became more luxurious, and offered more amenities, including a V6 engine. The second generation was more refined, and was available with two-wheel drive.

The Opel Monterey was a Japanese-built four-wheel drive Sports Utility Vehicle produced by General Motors. It was visually identical to the Isuzu trooper, but was only sold in Europe. Production began in 1994, with versions sold on Mainland Europe wearing Opel badges, and the British version being sold as a Vauxhall. Sales in Britain were disappointing, and the Vauxhall version of the car was withdrawn from sale at the end of 1998, though the Opel version continued to sell on the continent until 2002.
