2003 Infiniti QX4 3.5 4WD Luxury
Infiniti QX4 Problems
Engine problem
2001, After working on the vehicle engine it
cannot start. It's not bringing current to
...
Shuts off with a jerk
1997, shuts off ,mwith a jerk while running but
able tto start immediately?...
Timing chain setting
2001, i need original timing diagram for
setting the engine....
Body type | SUV |
---|---|
Power | 240 Hp |
Engine Displacement | 3500 cm3 or 3.5L or 213.5 cu-in |
Color | gold |
Transmission Gearbox | Automatic |
Fuel Type | Gasoline |
Drive wheel | 4WD |
Mileage | 102165 Miles |
Vin | JNRDR09Y43W****03 |
Price (out of date) | $8047 |
Frequently Asked Questions | |
---|---|
What is the body type, Infiniti QX4 SUV 2003? | SUV, 5 Seats, 4 Doors |
What is the fuel economy, Infiniti QX4 JR50 2003? | 13.8 l/100 km |
How fast is the car, 2003 Infiniti QX4 3.5 4WD Luxury? | 177 km/h, 0-100 km/h: 8.9 sec |
How much power, Infiniti QX4 2003 SUV 3.5 4WD Luxury (240 Hp)? | 240 Hp |
What is the engine size, 2003 Infiniti QX4 SUV 3.5 4WD Luxury (240 Hp)? | 3.5L or 3498cm3 |
How many gears, What type is the gearbox, Infiniti QX4 SUV 2003? | Automatic transmission 4 |
What is the drivetrain, Infiniti QX4 JR50 2003? | All wheel drive (4x4) |
How long is this vehicle, 2003 Infiniti QX4 3.5 4WD Luxury? | 4650 mm |
How wide is the vehicle, Infiniti QX4 2003 SUV 3.5 4WD Luxury (240 Hp)? | 1840 mm |
What is the gross weigh, 2003 Infiniti QX4 SUV 3.5 4WD Luxury (240 Hp)? | 2335 kg |
How much trunk (boot) space, Infiniti QX4 SUV 2003? | 1075 l |
Infiniti QX4 JR50 3.5 4WD Luxury (240 Hp) 2000, 2001, 2002, 2003 Specs
General information | |
---|---|
Complectation name | 3.5 4WD Luxury |
Production start year | 2001 |
Production end year | 2003 |
Drive type | All wheel drive (4x4) |
Frame type | SUV |
Transmission type | Automatic transmission 4 |
Engine volume, cc | 3498 |
Frame name | JR50 |
0 to 100 time | 8.9 |
Max speed | 177 |
Clearance, mm | 211 |
Manufacturing country | Japan |
Doors | 4 |
Warranty | 4 years or 60,000 miles |
Engine, transmission and steering specs | |
Engine specs | |
Engine name | VQ35DE |
Fuel | Petrol (Gasoline) |
Engine type | V6 |
Has turbo | no |
Max power, hp | 240 |
Max power RPM, rpm | 6000 |
Max power, hp (kWt) / rpm | 240 (177) / 6000 |
Max torque, N*m | 359 |
Max torque RPM, rpm | 3200 |
Max torque, N*m (kg*m) / rpm | 359 (37) / 3200 |
Valves per cylinder | 4 |
Compression ratio | 10.3 |
Bore, mm | 95.5 |
Stroke, mm | 81.4 |
Eco type | Euro-4 |
Fuel consumption | |
City | 15.7 |
Country side | 12.4 |
Combined | 13.8 |
Transmission | |
1st gear ratio | 2.78 |
2nd gear ratio | 1.54 |
3rd gear ratio | 1 |
4th fear ratio | 0.69 |
Rear gear ratio | 2.27 |
Main gear ratio | 4.36 |
Steering | |
Power steering | yes |
Dimensions | |
Frame dimensions | |
Exterior length, mm | 4650 |
Exterior width, mm | 1840 |
Exterior height, mm | 1730 |
Interior dimensions | |
Capacity | 5 |
Seat rows | 2 |
Interior length, mm | 1915 |
Interior width, mm | 1465 |
Interior height, mm | 1115 |
Chassis dimensions | |
Wheel base, mm | 2700 |
Turning radius, m | 5.2 |
Wheel spacing front | 1540 |
Wheel spacing rear | 1545 |
Weight and permissible load | |
Mass, kg | 1975 |
Max capacity | 360 |
Max. weight | 2335 |
Max towbar effort | 225 |
Trailer max weight wbrakes | 2270 |
Volumes | |
Fuel tank capacity, l | 80 |
Trunk volume | 1075 |
Other | |
Aerodynamic drag | 0.45 |
Suspension specs | |
Suspension specs | |
Front suspension | Independent, Spring McPherson |
Rear suspension | Dependent, multilever |
Wheel rims | |
Aluminium wheel | yes |
Front wheel disk | 17X8J |
Rear wheel disk | 17X8J |
Tires | |
Front wheels | 245/65 R17 |
Rear wheels | 245/65 R17 |
Brakes | |
Front brake | Ventilated discs |
Rear brake | drum brakes |
Exterior | |
Headlights | |
Xenon lamps | yes |
Diod head lights | no |
Front fog lamps | yes |
Rear fog lamps | no |
Light sensor | yes |
Side mirrors | |
Power adjustable door mirrors | yes |
Door mirrors heating | yes |
Doors | |
Power rear door | no |
Windows | |
Privacy glass | yes |
Rear glass heat | yes |
Roof | |
Tilt sunroof | yes |
Accessories | |
Back wiper | yes |
Rear mudflaps | yes |
Body color | |
Metallic paint Body | no |
Interior | |
Steering wheel and center panel | |
Leather winding | yes |
Adjustable steering | yes |
Telescopic steering | yes |
Tilt steering | yes |
Audio control on steering wheel | yes |
Tachometer | yes |
Env temp | yes |
Interior design | |
Leather upholstery | yes |
Panels | Wooden inserts on steering wheel, leather trim on automatic transmission knob |
Seats | |
Front seats ajust | Adjustment of the driver's seat in 8 directions, the passenger seat in 4 directions |
2nd row | 60/40 ratio fold seat |
Loin reliance | yes |
Headrests for seats | 4 |
Separating armrest front | yes |
Separating armrest rear | yes |
Seats pockets | yes |
Mats | yes |
Electric interior package | |
Power adjustable driver seat | yes |
Power ajustable front seat | yes |
Front seat heater | yes |
Rear seats heater | option |
Seat position memory | yes |
Centralized door lock | yes |
Keyless | yes |
Power window front | yes |
Power window rear | yes |
Additional interior equipment | |
Holders for bottles in doors | yes |
Smokers packet | yes |
AC plug | yes |
Safety | |
Airbags | |
Drivers airbag | yes |
Passengers airbag | yes |
Side airbag | yes |
Curtain airbags | option |
Active and passive safety | |
Active headrest | yes |
Safety belt pretensioner | yes |
Safety belt limiter | yes |
Electronic security and traffic control systems | |
ABS | yes |
Cruise control | yes |
Distance control system | option |
Front sonar | option |
Rear sonars | option |
Amenity | |
Microclimate | |
Air conditioner | yes |
Automatic air conditioning | yes |
Air filter | yes |
Audio systems | |
Radio | yes |
CD player | yes |
CD changer | yes |
Additional sound equipment | 6 speakers, antenna |
Navigation and video equipment | |
Navigation system | option |
Additional amenities | |
Anti-glare effect | yes |
Mirrors in sunshields | yes |
Lagage box | yes |
Blind in luggage compartment | yes |
Car safety | |
Security alarm | yes |
Driver Kit | |
Medkit | option |
Spare tire | yes |
The QX4 is noted as a luxury SUV powered by a standard 3.3-liter SOHC 12-valve V-6 with 168 hp paired with a 4-speed automatic transmission. It comes standard with it's unique 4 wheel drive system called All-Mode 4WD.
2003 Infiniti QX4 JR50 3.5 4WD Luxury (240 Hp) specs
|
In the North American market, it was marketed as the "Infiniti QX4" while in Japan it was sold as the "Nissan Terrano Regulus". Major differences between these vehicles and the Pathfinder include a more advanced four wheel drive system, a more upscale interior, and unique styling. Although marketed as a luxury vehicle, it is capable off-road service due to its low-range four wheel drive system and 8.3inches (211mm) of ground clearance. The QX4 received its first major update in 2001, with a new engine increasing its power from a relatively weak 168horsepower (125kW) to a comparative 240hp (179kW) V6 engine. The displacement went from 3.3L to 3.5L. The timing belt was replaced with a timing chain, and the more reliable ignition distributor was replaced with a problematic individual coil ignition system.[citation needed] This 2001 facelift also gave the QX4 an updated exterior and interior body style, including features such as a new dash with integrated clock, 17-inch (423 mm) alloy wheels and xenon HID headlamps. In Japan, the Terrano Regulus shortened its name to Terrano and was restyled like the Pathfinder instead. Also, a rear-wheel drive model was added. » Read More About Infiniti QX4 |
