1994 Chrysler Grand Voyager II 2.5 TD MT SE
Chrysler Grand Voyager Problems
Powersteering pump
1999, I have a 1999 voyager will a pwersteering
pump off a 2004 model fit I can purchase one t...
Chrysler Grand Voyager
1993, Hallo, can you help me, please? Where can
I buy a parts for my car? I need an on-line sh...
| Body type | Minivan |
|---|---|
| Power | 118 Hp |
| Engine Displacement | 2500 cm3 or 2.5L or 152.5 cu-in |
| Color | blue |
| Transmission Gearbox | Manual |
| Fuel Type | Diesel |
| Drive wheel | FF |
| Mileage | 186411 Miles |
| Vin | 1C4GH14KXRX****95 |
| Price (out of date) | $1736 |
Frequently Asked Questions | |
|---|---|
| What is the body type, 1994 Chrysler Grand Voyager II? | Minivan, 7 Seats, 4 Doors |
| How fast is the car, Chrysler Grand Voyager Minivan 1994? | 180 km/h, 0-100 km/h: 12.3 sec |
| How much power, Chrysler Grand Voyager ES 1994? | 118 Hp |
| What is the engine size, 1994 Chrysler Grand Voyager 2.5 TD MT SE? | 2.5L or 2499cm3 |
| How many gears, What type is the gearbox, Chrysler Grand Voyager II 1994 Minivan 2.5 TD MT SE (118 Hp)? | 5 speed Manual |
| What is the drivetrain, 1994 Chrysler Grand Voyager Minivan 2.5 TD MT SE (118 Hp)? | Front |
| How long is this vehicle, 1994 Chrysler Grand Voyager II? | 4525 mm |
| How wide is the vehicle, Chrysler Grand Voyager Minivan 1994? | 1830 mm |
| What is the gross weigh, Chrysler Grand Voyager ES 1994? | 2395 kg |
| How much trunk (boot) space, 1994 Chrysler Grand Voyager 2.5 TD MT SE? | 605 l |
Chrysler Grand Voyager II ES 2.5 TD MT SE (118 Hp) 1992, 1993, 1994, 1995 Specs
General information | |
|---|---|
| Complectation name | 2.5 TD MT SE |
| Production start year | 1992 |
| Production end year | 1995 |
| Drive type | Front |
| Frame type | Minivan |
| Transmission type | 5 speed Manual |
| Engine volume, cc | 2499 |
| Frame name | ES |
| 0 to 100 time | 12.3 |
| Max speed | 180 |
| Clearance, mm | 140 |
| Manufacturing country | USA |
| Doors | 4 |
Vehicle generation | |
| Generation name | ES |
| Generation number | 2 |
| Production start year | 1991 |
| Production end year | 1995 |
Engine, transmission and steering specs | |
Engine specs | |
| Engine name | VM425 |
| Fuel | Diesel |
| Engine type | In-line, 4-cylinder |
| Has turbo | yes |
| Turbo type | Turbine |
| Max power, hp | 118 |
| Max power RPM, rpm | 4200 |
| Max power, hp (kWt) / rpm | 118 (87) / 4200 |
| Max torque, N*m | 262 |
| Max torque RPM, rpm | 2200 |
| Max torque, N*m (kg*m) / rpm | 262 (27) / 2200 |
| Valves per cylinder | 2 |
| Compression ratio | 20.95 |
| Bore, mm | 92 |
| Stroke, mm | 94 |
Dimensions | |
Frame dimensions | |
| Exterior length, mm | 4525 |
| Exterior width, mm | 1830 |
| Exterior height, mm | 1688 |
Interior dimensions | |
| Capacity | 7 |
| Seat rows | 3 |
Chassis dimensions | |
| Wheel base, mm | 2853 |
| Turning radius, m | 6.25 |
| Wheel spacing front | 1522 |
| Wheel spacing rear | 1578 |
Weight and permissible load | |
| Mass, kg | 1630 |
| Max. weight | 2395 |
Volumes | |
| Fuel tank capacity, l | 76 |
| Trunk volume | 605 |
Suspension specs | |
Suspension specs | |
| Front suspension | Independent, Spring McPherson |
| Rear suspension | Dependent, spring loaded |
Wheel rims | |
| Disc | 14" |
Tires | |
| Front wheels | 195/75 R14 |
| Rear wheels | 195/75 R14 |
Brakes | |
| Front brake | Discs |
| Rear brake | drum brakes |
1994 Chrysler Grand Voyager II ES 2.5 TD MT SE (118 Hp) specs
|
Though no longer available in North America, Chrysler continues to use Chrysler Voyager nameplate in global markets, e.g., Mexico, Europe. Together with its nameplate variants, the Dodge Caravan, Chrysler Town & Country, Plymouth Voyager and Volkswagen Routan, the Chrysler minivans have ranked as the 13th bestselling automotive nameplate worldwide, with over 12 million sold. The European Chrysler Voyager was first released in 1988, nearly identical to its American counterpart, the Plymouth Voyager; the only visual differences between the two were the head/ taillights and grille. Besides of the slightly different appearance European Voyagers were sold with different engines, including diesel engines, which are popular in Europe; the trim was also different. The current European Voyagers are very similar to the 2008 Chrysler Town & Country cars. Although produced in Ontario now, they are still available with diesel engines. They are sold as Chrysler Grand Voyagers in Europe, since 2008 only in the long wheelbase version (as in North America). » Read More About Chrysler Grand Voyager |
