General data |
|---|
| Generation | Espace IV (Phase III) |
|---|
| Modification | 2.0 dCi (173 Hp) Automatic |
|---|
| Start of production | 2010 year |
|---|
| End of production | 2012 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Minivan, MPV |
|---|
| Seats | 7 |
|---|
| Doors | 5 |
|---|
| Fuel Type | Diesel |
|---|
| Model | M9R |
|---|
Fuel consumption (economy), emissions |
|---|
| Fuel consumption - urban | 9.3 l/100 km |
|---|
| Fuel consumption - extra urban | 6.1 l/100 km |
|---|
| Fuel consumption - combined | 7.2 l/100 km |
|---|
| CO2 emissions | 189 g/km |
|---|
| Emission standard | Euro 5 |
|---|
Performance specs |
|---|
| Acceleration 0 - 100 km/h (0 - 62 mph) | 11.1 sec |
|---|
| Maximum speed | 198 km/h |
|---|
| Weight-to-power ratio | 11.6 kg/Hp, 86.2 Hp/tonne |
|---|
Engine technical data |
|---|
| Power | 173 Hp @ 3750 rpm. |
|---|
| Power per litre | 86.7 Hp/l |
|---|
| Torque | 360 Nm @ 1750 rpm. |
|---|
| Engine location | Front, Transverse |
|---|
| Engine displacement | 1995 cm3 |
|---|
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore | 84 mm |
|---|
| Piston Stroke | 90 mm |
|---|
| Compression ratio | 16 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Diesel Commonrail |
|---|
| Engine aspiration | Turbocharger, Intercooler |
|---|
| Valvetrain | DOHC |
|---|
| Engine oil capacity | 6.6-8.2 l |
|---|
| Engine systems | Particulate filter |
|---|
Suspension and brakes specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (automatic transmission) | 6 |
|---|
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|
| Rear suspension | Semi-independent, coil spring |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Tires size | 225/55 R17 |
|---|
| Wheel rims size | R17 |
|---|
Dimensions |
|---|
| Length | 4661 mm |
|---|
| Width | 1894 mm |
|---|
| Height | 1801 mm |
|---|
| Wheelbase | 2803 mm |
|---|
| Front track | 1574 mm |
|---|
| Rear (Back) track | 1556 mm |
|---|
| Front overhang | 1026 mm |
|---|
| Rear overhang | 832 mm |
|---|
| Ride height | 175 mm |
|---|
| Minimum turning circle (turning diameter) | 11 m |
|---|
Weights, volume and space |
|---|
| Kerb Weight | 2008 kg |
|---|
| Max. weight | 2640 kg |
|---|
| Max load | 632 kg |
|---|
| Trunk (boot) space - minimum | 291 l |
|---|
| Trunk (boot) space - maximum | 2860 l |
|---|
| Fuel tank capacity | 83 l |
|---|
| Max. roof load | 80 kg |
|---|
| Permitted trailer load with brakes (12%) | 2000 kg |
|---|
| Permitted trailer load without brakes | 750 kg |
|---|
| Permitted towbar download | 80 kg |
|---|
Renault Espace IV (Phase III) 2.0 dCi (173 Hp) Automatic has been in production since 2010 - 2012. Cars comes in Minivan, MPV body types and can be suited with Diesel engine types with a volume of 2L liters, engines produces a power of 173 Hp. Fuel consumption of Renault Espace IV (Phase III) 2.0 dCi (173 Hp) Automatic is 7.2 l/100 km.
